Detail Information

Name:	Metal Wide Belt Sander	Type:	Sanding
Function:	Deburring, Grinding, Slag Removal, Finishing	Max Working Width:	1350mm
Weight:	3.9 Ton	Table Lifting Motor:	1.5kw
Highlight:	3.9ton Metal Wide Belt Sander , Finishing Metal Wide Belt Sander , Slag Removal Metal Wide Belt Sander

Product Description

Metal Wide Belt Sander

General Description

This is a metalworking wide belt sander for deburring, sanding,polishing, finishing, slag removal and texturing.With 2 powerful sanding drums and vacuum sucking work-table, the metal wide belt sander can process wide metal sheets, plates,middle and small size metal work-piece in an effective way for deburring, grinding and finishing.With a quick change of the abrasive belt, this metal wide belt sander can do slag removal and oxide removal of the metal parts done by plasma cut or flame cut .

The metal wide belt sander is designed for one wide part or multi smaller parts processed in a production line or in an independent way. Vacuum sucking work-table can fix minimum 100mm smaller parts on the conveyor belt to insure a good deburring or finishing.Either high productivity in a flow line or reliable effects for smaller parts, this metal wide belt sander will not let you down, but saving labor and time.

FEATURES

1350mm max working width
Digital thickness readout for conveyor height
Control panel with motor load meter,digital readout
Electronic abrasive belt tracking
Pneumatic abrasive tensioning
High quality contact drum
Robust welded frame

SPECIFICATIONS

Power supply: 380v 50Hz or on request
Dust port size: drum 150mm x 6, space 100mm x 4
Automatic Thickness Control: Yes (Thickness or)
Foot Print: 51-1/2″ x 19″
Sanding Belt Oscillation: Yes
Sanding Belt Motor Break: Yes
Conveyor Opening 0-80mm
Floor to Table Height 900-990mm
Conveyor Drive Motor 5.5kw
Feed Speed 5-25 meter per minute variable
Dimension 2200x2500x2300mm WxDxH
Weight 3.9 ton
Work piece Max Width 1350mm
Work piece Max Thickness 60mm
Work piece Min. Length 100mm

3.9ton Metal Wide Belt Sander For Polishing / Finishing / Slag Removal 0

Tag:

Place of Origin:	China
Brand Name:	SKD
Model Number:	MS13RR
Document:	Product Brochure PDF

Minimum Order Quantity:	1 set
Price:	USD10000-350000
Packaging Details:	Shrink Wrapped or Woodcase
Delivery Time:	20-60 days
Payment Terms:	TT
Supply Ability:	70-100set per year

3.9ton Metal Wide Belt Sander For Polishing / Finishing / Slag Removal
