Precision Metal Deburring Machine Durable For Stainless Steel / Aluminium

Metal Deburring Machine

General

The belt and disc metal deburring machine sets itself apart in several ways. Firstly, it is equipped with not just one, but two deburring discs and two edge rounding discs. This double-disc configuration allows for simultaneous deburring and edge rounding, saving time and increasing efficiency.

Furthermore, the machine's discs do more than just oscillate continuously over the workpiece during throughfeed. They are equipped with advanced motion control technology, enabling precise and customizable oscillation patterns. This level of control ensures consistently high-quality deburring and edge rounding results, even on complex shapes and challenging materials.

But what truly makes this machine stand out is the extensive range of disc tools available. With a wide variety of shapes, sizes, and abrasive grits, the machine can adapt to different deburring and edge rounding applications. Whether it's removing heavy burrs, achieving fine edge radii, or anything in between, there's a disc tool suited for the task.

In summary, the belt and disc metal deburring machine goes beyond the standard by offering a dual-disc configuration, advanced motion control, and a diverse selection of disc tools. These features combine to deliver exceptional deburring and edge rounding results with versatility and precision.

SPECIFICATIONS

• Even wearing of abrasive tools irrespective of the size of the workpiece or where it is placed on the conveyor belt.
• Quick change of tools when switching between materials – only four discs need to be changed
• Large variety of disc tools available makes the machine very versatile
• For deburring and edge rounding laser-cut, plasma-cut and water-cut parts
• For deburring and edge rounding 3D punched parts
• For edge rounding and orbital finishing in one pass
• Processing of small parts from 20mm x 20mm
• Processing of foil-covered or zinc-plated parts
• Processing of steel, stainless steel and aluminium
• Working widths: 1000mm, 1500mm and 2000mm
• Smallest part size: 20mm x 20mm
• Material thickness: 0,3mm – 70mm (100mm)
